CPU
 |
INTEL® Cedar Trail-M Processor N2600 (1.6GHz)
            INTEL® Cedar Trail-M Processor N2800 (1.86GHz)
 |
|
Chipset
 |
INTEL®NM10 Express chipset
 |
|
Memory
 |
1 * DDR3 800MHz Single CH SO-DIMM up to 2GB (For Cedar Trail-M N2600)
            1 * DDR3 1066MHz Single CH SO-DIMM up to 4GB (For Cedar Trail-M N2800)
 |
|
Expansion Slots
 |
1 * MINI PCI-E
 |
|
Storage
 |
1 * Serial ATAII 3Gb/s connectors
            1 * CFast card socket
 |
|
Audio
 |
Realtek ALC662 HD Audio CODEC with 4-Channel
 |
|
Ethernet LAN
 |
2 * RTL8111E PCI-EVL Gigabit LAN
 |
|
USB
 |
Embedded 7 * USB 2.0/1.1
 |
|
LVDS
 |
Onboard 1 * 24-bits Dual channel & 1 * 18-bits Single LVDS connectors
 |
|
Rear Panel I / O
 |
4 * USB 2.0/1.1 ports
            2 * RJ-45 ports
            Line-out port
            1 * DVI-I port
            1 * 12V DC-IN JACK
 |
|
Internal I / O
 |
2 * USB 2.0 header for 3 * USB 2.0 ports
            1 * Audio header
            System/Chassis/NB Fan Connectors
            1 * GPIO header
            1 * CFast card reader socket
            DIY switch x2 (reset & power button)
            4 * COM header (COM1~3 for RS232,COM4 for RS232/422/485)
 |
|
BIOS
 |
AMI 16MB SMT Flash ROM
 |
|
Form Factor
 |
3.5” SBC form factor (148mmx102mm)
 |
|
Certificate
 |
CE,FCC,RoHS,ERP
 |
|
Functional
 |
ATM, Automation, Medical Equipment, Security, General Application, Transportation, Digital Signage, Kiosk, POS machine, LCD TV PC, Embedded Fanless application
 |
|
Temperature
 |
Operating within 0~60 centigrade
            Storage within -20-85 centigrade |

Well designed and works great! Even has a modern UEFI BIOS, adaptive fan control and overheat protection.
The only problem I had was finding a suitable power adapter. Perhaps I missed it, but neither the manual nor the spec sheet lists the size and polarity of the DC input jack. I just tried extras I had around until one fit.
